Revelo Joy
HIGHLIGHTS
- - Frame: Alloy 6061, sizes: 44/ 48/ 52 cm
- - Fork: Suntour NEX HLO
- - Rear derailleur: Shimano CUES RD-U3020 SGS
- - Wheels: 28"
- - Weight: 16.8 kg
- - Colors:
SPECIFICATION
FRAMESET
DRIVETRAIN
Shifters: Shimano CUES
SL-U4000-9R2x9 speed
Crankset: Shimano CUES FC-U4010-2
Chainrings: 46-36, length: 175mm
Chain: KMC X-Glide
9 speed
WHEELS
Front hub: HUB DYNAMO,
DH-3D32-QR 100mm
Rear hub: HUB 14G 32H*M10*135mm
32H*M10*135mm
COMPONENTS
Brakes: Shimano BL-MT200
Disc brakes: 160/160mm
Handlebar: HBC
Width: 660mm, 25.4mm, bended
Stem: HBC
Length: 50cm-85mm, 55cm-95mm, 59cm-105mm, 25.4mm
Seatpost: HBC
Length: 350mm, 27.2mm
Based on components availability HEAD Bike reserves the right to vary specifications, including colors, with or without notice. Major as well as minor changes may be involved. Bike and frame weights are based on pre-production painted frames at the time of publication. The range of the e-bike depends on many factors such as the rider’s weight, the track profile, the level of assistance, gear settings, the wind, etc., so the information is indicative and may vary. Consult your Distributor or Dealer for details regarding the specifications of any featured product.
GEOMETRY
FIND YOUR SIZE
Your height:
Choose your height
Recommended bike size:
*The recommendation covers the most common body types. Contact your local dealer if you need more assistance.
medium size - 50cm
large size - 55cm
x-large size - 59cm
